TRICONEX+3805E 4508

Description

The TRICONEX 3805E 4508 DCS PLC Module is part of the Triconex family of safety and control systems, which are widely used in process industries for critical control and safety applications. Below is a detailed breakdown of the product name, description, parameters, and specifications for this module:

Product Name:

TRICONEX 3805E 4508 DCS PLC Module

Product Description:

The TRICONEX 3805E 4508 module is a Distributed Control System (DCS) and Programmable Logic Controller (PLC) module used in industrial automation, safety systems, and process control. It is part of the Triconex Safety System, a highly reliable, fault-tolerant system designed to meet the stringent requirements of critical processes in industries such as oil & gas, petrochemical, chemical, power generation, and other sectors where safety and uptime are paramount.

The Triconex 3805E is designed to work within the Triconex Tricon Controller and Tricon Safety Systems, providing reliable process control and ensuring operational continuity in case of failure. The module integrates seamlessly into larger control systems, offering monitoring, fault detection, and fail-safe functionalities to protect equipment and personnel in high-risk environments.

Key Features:

• High Availability & Fault Tolerance: Designed for continuous operation with built-in redundancy for maximum uptime.
• Safety Integrity Level (SIL) 3 Compliance: Meets rigorous international standards for functional safety, such as IEC 61508, IEC 61511, and others.
• Real-Time Diagnostics & Monitoring: Provides detailed diagnostic information to detect faults and prevent system failures.
• Scalable & Modular Design: Can be scaled to meet the specific needs of large or small systems, providing flexibility.
• Communication Capabilities: Supports various industrial communication protocols for easy integration with other systems.

Product Parameters and Specifications:

1. Form Factor:
   • Rack-mounted, modular design that can be installed in the Triconex system racks.
2. I/O Points:
   • Typically integrates with the Triconex I/O modules, which can vary in number depending on the configuration.
3. Redundancy:
   • Dual processor design for fault tolerance and system availability.
   • Hot swappable to minimize downtime during maintenance.
4. Inputs/Outputs:
   • Digital and analog inputs and outputs can be configured, depending on the specific application and module type.
   • Supports both discrete (on/off) and analog (continuous) signals.
5. Communication Protocols:
   • Common protocols include Modbus, Ethernet/IP, Profibus, and Fieldbus.
   • Triconex controllers are also integrated with proprietary communication protocols for high-performance control.
6. Safety Certification:
   • SIL 3 (Safety Integrity Level): Compliance with international safety standards for hazardous process control environments.
   • Meets IEC 61508 and IEC 61511 for functional safety.
7. Operating Temperature:
   • Ambient temperature range: Typically 0°C to 60°C (32°F to 140°F), depending on environmental conditions and installation setup.
8. Power Supply:
   • The TRICONEX system typically operates on 24V DC power.
9. Memory:
   • Non-volatile memory for storing critical configuration and safety parameters.
   • Supports large programs and data storage for process control logic and safety monitoring.
10. Failure Modes & Diagnostics:

• Comprehensive diagnostics and fault detection capabilities built into the module.
• Self-checking circuits and redundant processing paths ensure system robustness.

1. Mounting:

• Designed for mounting in standard racks or control panels, with easy access for replacement or service.

1. Certification:

• ATEX/IECEx (Explosion Proof) certified for use in hazardous areas, in certain configurations.

1. Size and Weight:

• • The size will depend on the rack or system used but typically is around 5-10 inches in height with variable depth depending on the application.
  • Weight is around 2-3 kg (depending on the configuration).
